NEVER USE “PINK” PACKING MATERIAL FOR BOARD TRANSPORT OR AS A WORK SURFACE. While many people think pink packing material is ESD safe, in most cases it easily builds up unwanted charge. Unless continuous, thorough testing is done, treat pink packing materials as charged.
CAP UNUSED EQUIPMENT INPUTS to avoid accidental ESD and physical damage. Damage often occurs by accidentally contacting equipment inputs. Capping unused inputs protects them from incidental ESD damage.
USE ESD-SAFE BAGS WHEN TRANSPORTING BOARDS. This protects boards from ESD damage while moving between ESD-safe locations.
DO NOT OVERDRIVE EQUIPMENT INPUTS. Start your testing at the least sensitive input setting and zoom in on your signal. Additionally, observe the maximum input levels for your specific equipment. The least sensitive setting is the most resilient, so starting there ensures that your inputs are at safe operating levels
After I posted this to my blog, Dave, N8SBE offered some further tips. He writes:
Grounded heel straps also help reduce static charge. Test them with a floor tester every time you put them on. The floor needs to be somewhat conductive—not metal, that’s a safety hazard—so use conductive wax on tiles, or conductive carpet to drain of electrostatic charges.
Keep materials, such as styrofoam cups, that form electrostatic charges easily away from your workspace. A styrofoam cup can generate thousands of volts.
Keep the humidity up in the workspace. That helps to keep static generation down as well.
I like to think that I follow ESD-safe procedures, but there are a couple of things here that I hadn’t thought about before. For example, I’d never really thought about discharging test equipment cables before connecting them. I think that’s a good tip
To learn more, go to https://www.keysight.com/find/PreventESD
Dan Romanchik, KB6NU, is the author of the KB6NU amateur radio blog (KB6NU.Com), the “No Nonsense” amateur radio license study guides (KB6NU.Com/study-guides/), and often appears on the ICQPodcast (icqpodcast.com). When he's not worrying about electrostatic discharge, he teaches online ham radio classes and operates CW on the HF bands.
